Rotary Actuator


Rotary ActuatorRotary Actuator


General Description :
Rotary actuator finds application in 90 degree angular movement. (180 deg. on request) & are most suitable for closing & opening of ball valve, butterfly valve, damper positioning, sorting Equipments, indexing mechanisms, furnace doors, dueling flaps etc.

With Flange End Ball Valve
M.O.C.-S.S.316 (ASTM-A-351 CF8M), S.S.304 (ASTM-A-351 Gr.CF8), C.S. (ASTM-A-216 GR. WCB) Manufacturing Range 1/2 inch (15mm) to 4 inch (100mm) (Upto 8 inch on Request)

With Screwed End Ball Valve
M.O.C-S.S. 316 (ASTM-A-351 CF8M), S.S.304 (ASTM-A-351 Gr. Cf8),
C.S. ( ASTM-A-216  Gr. WCB)
Manufacturing Range :
1/2 inch (15mm) to 2 inch (50mm)

With Socket Weld Ball Valve
M.O.C.-S.S.316 (ASTM-A-351CF8M), S.S.304 (ASTM-A-351 Gr.CF8),
C.S. (ASTM-A-216 Gr. WEB)
Manufacturing Range :
1/2 inch (15mm) to 2 inch (50mm)

With 3 way Ball valves
M.O.C.-S.S.316, S.S. 304, C.S.
Manufacturing Range :
1/2 inch (15mm) to 2 inch" (50mm)

Working of our rotary actuators
It is designed to use two opposite moving pistons with the help of rack & pinion mechanism to generate powerful uniform torque. When air is admitted in one port pinion rotates in one direction at the same time air is exhausted through the other port & vice-versa.

This offers a very compact design to give powerful torque and works maintenance free for years.

We also deal in all types of Pneumatic Accessories like straight, Elbow, T, Flow Control, Union elbow, Equal T, Cross, Multiple T, 'Y', etc. Also coupling, tubings all PU, Hoses, Hydraulic Hose. For Pneumatic working pressure for tube is 15kg/cm2
